• Switching :25mA at 24VDC
• Non-Switching :100mA at 50VDC
Contact Resistance
• Initial :50MΩ Max
• After life :100MΩ Max
• Insulation Resistance :100MΩ Max,Minat100VDC
• Dielectric Strength :300VAC for 60 seconds
• Switch Capacitance :5pF Max at 1MHZ
• Operation Temperature : -30°C to +85°C
• Storage Temperature : -40°C to +85°C
Mechanical Processing
• Operation Force :500gf Max
• Mechanical Life : 1000 cycles Operations
• Resistance to Soldering : 270°C15C for 10 second
• Packing: All DIP Switches Are Slipped In Standard lC
Tubes Or Reel Package With All Poles In The " OFF |
|
Part Number | Initial | After life | Insulation Resistance | Dielectric Strength | Operation Temperature | Operation Force | Mechanical Life | Resistance to Soldering | PDF下載 |
---|---|---|---|---|---|---|---|---|---|
RHP | 50MΩ Max | 100MΩ Max | 100MΩ Max,100VDC | 300VAC for 60 seconds | -30℃ to +85℃ | 500gf Max | 1000cycles | 270℃±5℃ for 10 second | 暫無 |
